| CPU Sockets |
1x Socket |
| CPU Support |
Intel Xeon E-2100/E-2200; Intel Core i3 Gen 8th/9th ; Intel Celeron; Intel Pentium |
| RAM Support |
4x DIMM slots; Up to 128GB DDR4-2666MHz Unbuffered ECC UDIMM |
| Drive Bays |
4 Hot-swap 3.5″ |
| M.2 Interface |
1x SATA/PCI-E 3.0 x4 and 1x PCI-E 3.0 x4; 2280/22110 |
| RAID Controller |
Intel C246 |
| RAID Support |
RAID 0, 1, 5, 10 |
| Form Factor |
1U |
| PCIe |
1 PCI-E 3.0 x16 slot |
| I/O Ports |
2x USB 3.1 ports (rear); 2x USB 2.0 ports (rear); 1x VGA port; 1x COM port (header); 1x TPM 2.0 Header |
| Network Interface |
2 x RJ45 1GbE LAN ports; 1 x RJ45 Dedicated IPMI LAN port |
| Power Supply |
350W |
| Redundant Power |
NO |
| System Fan |
4x 40x28mm PWM fans |
